Rheinhütte Pumpen Pump Typ RCE - Chemical centrifugal pump in metal

RCE – Chemical centrifugal pump in metal

Model: RCE

The RCE is a horizontal single-stage, end-suction, top-discharge, centrifugal pump with heavy duty bolted-down bearing pedestal. The sturdy design with front and back vanes on the impeller is primarily intended to fulfil very specific requirements as a standard chemical pump. As a product-related special version, the RCE is the first choice in the chemical industry, the basic industry - especially in fertilizer production - environmental technology and many other industrial sectors.

It pumps organic and inorganic as well as aggressive liquids with high solid contents and is particularly suitable for hot media up to 450 degrees. Examples of applications include ammonium nitrate, molten sulphur, phosphoric acid, tar, pitch, urea melt, caustic soda, water glass, mash and cataphoretic paints.

Technical Data

Design
Horizontal centrifugal pump

Impeller
Closed or open

Temperature
-40 °C to 450 °C (-40 °F to 842 °F)

Material
Plastics

Delivery rate
Q_max. = 1.200 m³/h

Nominal pressure
up to 16 bar

Size
DN 32 - DN 300

Delivery head
H_max. = 180 m

Heavy-duty applications in chemically aggressive and abrasive media with or without a solids content, in chemical processing technology, the primary materials industry and other areas of industry. Typical applications are molten salt, pitch, tar, sulphur, etc.
